SAE Washer/Heavy Washer, 1/4" - 3", Black Oxide

One Pallet For One Size
MOQ
SAE Washer/Heavy Washer, 1/4" - 3", Black Oxide
Features Gallery Product Description Request A Quote
Features
Specifications
Name: SAE Washer/Heavy Washer
Material: S45C/40CR
Size: 1/4" - 3"
Finish: Plain/black/ZINC/HDG/Dacromet
Standard: SAE
Hardness: HV300/HRC35-45
Application: Construction, Bridges, Machinery And Automobile Manufacturing
High Light:

1/4"-3" SAE Heavy Washer HDG

,

1/4"-3" hardened stainless steel washers

,

SAE HDG hardened stainless steel washers

Basic Infomation
Place of Origin: China
Brand Name: YNK
Certification: ISO9001;ISO14001;ISO45001;CE
Model Number: SAE
Payment & Shipping Terms
Packaging Details: Pallet
Payment Terms: T/T
Supply Ability: 50T For 1 day
Product Description

Standard:SAE

Description:

      SAE washers, also known as heavy washers, are designed to provide a larger bearing surface and distribute the load when used with bolts or screws. They conform to the Society of Automotive Engineers (SAE) standards and are commonly used in various applications. The size range you mentioned, 1/4" to 3", refers to the diameter of the bolt or screw they are designed to work with.

      When specified with a "Black Oxide" finish, SAE washers have undergone a surface treatment process known as black oxide coating. Black oxide coating, also known as blackening, is a conversion coating that creates a thin layer of black oxide on the surface of the washer.

      The black oxide coating serves multiple purposes. First, it provides a degree of corrosion resistance, although its level of protection may not be as high as that of other coatings like hot-dip galvanizing or Dacromet. Second, the black oxide finish enhances the aesthetics of the washers, giving them a sleek black appearance. Lastly, the black oxide layer can improve the wear resistance and lubricity of the washers, facilitating smooth assembly and operation.

      SAE washers with a black oxide finish are commonly used in various industries where both functionality and visual appeal are important. They find applications in automotive, construction, machinery, and more. However, it's essential to consider the specific requirements of your application, including environmental conditions and load requirements, to ensure that the black oxide finish meets your needs.

      Please note that while black oxide coating provides some corrosion resistance, it may not offer the same level of protection as other specialized coatings. If high levels of corrosion resistance are required, alternative coatings or finishes, such as hot-dip galvanizing or Dacromet, may be more suitable.







Material 45#/40CR
Size 1/4"-3"
Finish Plain/black/ZINC/HDG/Dacromet/Mechanical Galvanized
Hardness HV300/HRC35-45
Marking can be Customized
Application Constrution/Wind turbines/railway line
Packing Carton+ pallet; we can pack washers as your requirements
Terms FOB+shanghai/ningbo
Delivery time 30-70days





Size

Inner

diameter(max)

Inner

diameter(min)

Outside

diameter(max)

Outside

diameter(min)

Thickness

(max)

Thickness

(min)

1/4" 16.26 15.75 7.52 7.01 2.03 1.3
5/16" 17.36 17.3 9.12 8.61 2.03 1.3
3/8" 21 20.45 10.59 10.19 2.03 1.3
7/16" 23.8 23.24 12.29 11.79 2.03 1.3
1/2" 27.74 26.8 13.87 13.36 3.07 1.88
9/16" 30.12 29.18 15.47 14.96 3.07 1.88
5/8" 34.09 33.15 17.42 16.48 3.07 1.88
3/4" 38.07 37.13 21.39 20.45 4.06 2.74
7/8" 45.21 44.27 24.58 23.65 4.06 2.74
1" 51.56 50.62 27.74 26.8 4.06 2.74
1-1/8" 57.91 56.97 32.51 31.57 4.06 2.74
1-1/4" 64.26 63.32 35.69 34.75 4.88 3.45
1-3/8" 70.61 69.67 38.86 37.92 4.88 3.45
1-1/2" 76.96 76.02 42.04 41.1 4.88 3.45







Products pictures for Flat washers

SAE Washer/Heavy Washer, 1/4" - 3", Black Oxide 0SAE Washer/Heavy Washer, 1/4" - 3", Black Oxide 1

SAE Washer/Heavy Washer, 1/4" - 3", Black Oxide 2
